Air flow at 1 speed - extractor by EN 61591 281 m3/h |
Air flow at 2 speed - extractor by EN 61591 342 m3/h |
Air flow at 3 speed - extractor by EN 61591 442 m3/h |
Air flow at 4 speed - extractor by EN 61591 703 m3/h |
Air Flow at Intensive or Boost Setting [If Available] 703 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 442 m3/h |
Air Flow at Minimum Speed in Normal Use 281 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 429 m3/h |
Air Pressure at Best Efficiency Point P BEP 392 Pa |
Éves energiafogyasztás 58.9 kWh |
Éves energia fogyasztás 58.9 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 729 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 250 x 300 x 9 mm |
Display color Red |
Distance from light cover to wall 2 cm |
Distance to electric hob 45 cm |
Distance to gas hob 65 cm |
Electric Power Input at Best Efficiency Point - W BEP 159 W |
Energy Efficiency Index - EEI hood 55.6 |
Fluid Dynamic Hatékonyság 29.4 |
Fluid Dynamic Hatékonyság A |
Grease Filtering Efficiency - GFE hood 58.1 % |
Zsírszűrési hatékonyság E |
Gross volume 0.2499 m³ |
Intensive or Boost Setting Auto-Off time 8 ' |
Internal/external motor Internal |
Világítás 121.5 lux/W |
Világítási hatékonysági osztály A |
Világítás A |
Limitation of Exhaust Air - t limit 9 ' |
Maximum Possible Air Flow 727 m3/h |
Motor unit rated power 260 W |
Motor type/model S-45 004 01 |
Net depth 42.5 cm |
Net height max 121 cm |
Net height min 105 cm |
Nettó tömeg 19.76 kg |
Net width 60 cm |
Zajszint 49 dB |
Zajszint 53 dB |
Zajszint 58 dB |
Zajszint 67 dB |
Nominal Power of the Lighting System - W L 6 W |
Number of motor units 1 |
Number units of main lighting 2 |
Légkifújó átmérője 15 cm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.25 W |
Power cabel length 170 cm |
Power rating 266 W |
Tápfeszültség 230V |
Power unit of main lighting 3 W |
Zajszint 67 dB |
Sound Power Emission at Intensive or Boost Setting [if available] 67 dB |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 58 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 49 dB |
Zajszint 58 dB |
Time Increase Factor - f 0.9 |
Type of main lighting LED |
